The KYN28-12 Armored Removable Enclosed Switchgear is an indoor AC metal-clad mid-mounted switchgear designed for three-phase 12 kV, 50 Hz medium-voltage power systems. It is suitable for receiving and distributing electrical energy while providing control, protection, and monitoring for a wide range of industrial and utility applications.
Developed in accordance with GB3906-2006, GB11022-89, IEC 298, and DL404-97, this switchgear adopts an armored metal-enclosed structure with a removable withdrawable unit (handcart type). The cabinet is manufactured using CNC processing and riveted construction, ensuring a high mechanical strength and a stable protection level of IP4X for the enclosure and IP2X when compartment doors are open.
The internal layout consists of four independent compartments—busbar, circuit breaker, cable, and low-voltage instrument rooms—providing clear functional separation, safe operation, and excellent fault isolation. With flexible installation options, the KYN28-12 can be arranged back-to-back, side-by-side, or against a wall, improving installation convenience and reducing substation footprint.
KYN28-12 is an indoor AC metal armored mid-mounted switchgear.
Suitable for three-phase AC power systems with a rated voltage of 12kV and a rated frequency of 50Hz.
Used for receiving and distributing electrical energy, as well as controlling, protecting, and monitoring circuits.
Complies with standards:
GB3906-2006 "3.6~40.5kVAC Metal Enclosed Switchgear and Control Equipment"
GB11022-89 General Technical Conditions for High Voltage Switchgear
IEC298 (1990) "AC metal enclosed switchgear and control gear with rated voltage above 1kV and below 50kV"
DL404-97 Technical Conditions for Ordering Indoor AC High Voltage
